Shell Mill Holder For Cutters With Driving Slot

* d=Ø40 (M12) , With additional 4 screws holes in compliance with DIN 2079

ORDER NO	BT	Form	A	d	D	D1	L1	L3	Kg
405.11.16.40	BT 40	JD	40	16	38	-	-	17	1.14
405.11.16.100	BT 40	JD	100	16	38	-	-	17	1.67
405.11.22.40	BT 40	JD	40	22	48	-	-	19	1.25
405.11.22.100	BT 40	JD	100	22	48	-	-	19	2.10
405.11.27.40	BT 40	JD	40	27	60	-	-	21	1.41
405.11.27.100	BT 40	JD	100	27	60	-	-	21	2.73
405.11.32.50	BT 40	JD	50	32	78	-	-	24	1.93
*405.11.40.50	BT 40	JD	50	40	88	-	-	27	2.13
405.11.16.200	BT 40	JD	200	16	38	45	120	17	2.69
405.11.22.200	BT 40	JD	200	22	48	55,5	120	19	3.67
405.11.27.200	BT 40	JD	200	27	60	-	-	21	4.94
405.11.16.160	BT 40	JD	160	16	38	44	88	17	2.30
405.11.27.160	BT 40	JD	160	27	60	-	-	21	4.05
405.11.32.100	BT 40	JD	100	32	78	-	-	24	3.79
405.11.32.160	BT 40	JD	160	32	78	-	-	24	6.02
405.11.22.160	BT 40	JD	160	22	48	54,5	88	19	3.07
405.11.32.200	BT 40	JD	200	32	78	-	-	24	7.51
405.11.16.130	BT 40	JD	130	16	38	-	-	17	1.96
405.11.22.130	BT 40	JD	130	22	48	-	-	19	2.52
405.11.27.130	BT 40	JD	130	27	60	-	-	21	3.39
405.11.32.130	BT 40	JD	130	32	78	-	-	24	4.90
406.11.16.40	BT 40	JF	40	16	38	-	-	17	1.11
406.11.22.40	BT 40	JF	40	22	48	-	-	19	1.21
406.11.27.40	BT 40	JF	40	27	60	-	-	21	1.36
406.11.32.50	BT 40	JF	50	32	78	-	-	24	1.87
*406.11.40.50	BT 40	JF	50	40	88	-	-	27	2.07
406.11.22.100	BT 40	JF	100	22	48	-	-	19	2.00
406.11.27.100	BT 40	JF	100	27	60	-	-	21	2.63
406.11.16.100	BT 40	JF	100	16	38	-	-	17	1.62
406.11.32.100	BT 40	JF	100	32	78	-	-	24	3.68
406.11.16.160	BT 40	JF	160	16	38	44	88	17	2.22
406.11.22.160	BT 40	JF	160	22	48	54,5	88	19	2.92
406.11.27.160	BT 40	JF	160	27	60	-	-	21	3.90
406.11.32.160	BT 40	JF	160	32	78	-	-	24	5.86
406.11.22.130	BT 40	JF	130	22	48	-	-	19	2.40
406.11.27.130	BT 40	JF	130	27	60	-	-	21	3.27
406.11.16.130	BT 40	JF	130	16	38	-	-	17	1.89
406.11.32.130	BT 40	JF	130	32	78	-	-	24	4.77
406.11.16.200	BT 40	JF	200	16	38	45	120	17	2.68
406.11.22.200	BT 40	JF	200	22	48	55,5	120	19	3.66
406.11.27.200	BT 40	JF	200	27	60	-	-	21	4.93
406.11.32.200	BT 40	JF	200	32	78	-	-	24	7.50
